GN-PSK30-ST200





GN-PSK30-ST200


General Features:

HD 4 in 1 AHD Camera
Hybrid 4in1: AHD/TVI/CVI/CVBS
Resolution: 2MP / 1080P
Lens: 2.8mm
IR Range: 15~20M
Outdoor IP66 Waterproof







Image Sensor

1/2.8" CMOS SONY IMX307+NVP2441H

Resolution

2MP (1920x1080)

TV System

PAL / NTSC

Video Output Mode

Hybrid 4in1: AHD/TVI/CVI, CVBS 960H

Lens

2.8mm Wide Angle Lens

Day & Night

IR-CUT Auto

Infrared LED

SDM IR LED*12pcs

Infrared Range

15~20M

Low illumination

0.01Lux @F.20,  0 Lux with IR LED on

OSD Menu

Support Multi Language OSD Menu

Other Functions

D-WDR, 3D-NR, Auto Gain Control, Auto White Balance

Waterproof Level

Al-Alloy+Plastic Dome Housing, IP65 Waterproof

Working Temperature

-10℃~50, RH95% Max

Power Source

DC12V±10%,  400mA

Camera Size

Φ105x69(H)mm

Gross Weight

0.38Kg
